FEATURES
Easy network setup with your iPhone / iPad
POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce installation costs
ONVIF standard supported to simplify system integration
External alarm I/O device connection
IR LED built-in for night surveillance with effective range up to 10 meters
Remote Surveillance
-- Fully compatibility
on iPhone & iPad, and Internet Explorer® on Windows® operating system
SPECIFICATIONS
▓ Network
Network Compression H.264 / MPEG4 / MJPEG
Multiple Video Streaming
(Encode Modes, IPS, Resolution) 3 (H.264, MJPEG, MPEG4)
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP,
HTTP, RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS
ONVIF Compatible YES
Frame Rate NTSC:30, PAL:25
Number of Online Users 10
Security
(1) Multiple user access levels with password
(2) IP address filtering
(3) HTTPS
(4) Digest authentication
Remote Access (1) Internet Explorer on Windows operating system
(2) EagleEyes on iPhone, iPad & Android mobile devices
▓ Camera
Image Sensor 1/4" SONY HR image sensor
Video Resolution SXGA, SXVGA, 720P, VGA, QVGA
Min Illumination 0.1 Lux / F1.5, 0 Lux (LED ON)
S/N Ratio More than 48dB (AGC off)
Lens f3.8mm / F1.5
Viewing Angle 62.7°(Diagonal)
▓ Camera
IR LED 12 units
IR Effective Range Up to 10 meters
White Balance ATW
AGC Auto
IRIS Mode AES
PIR Sensor YES
External Alarm I/O YES
Microphone YES
Speaker YES
Power Source (±10%) 5V / 1A
Operating Temperature 0 ℃~40℃
▓ Others
Mobile Surveillance iPad / iPhone / Android mobile device
Motion Detection YES
Event Notification FTP / Email / SMS
RTC (real-time clock) YES
Digital Pan / Tilt / Zoom YES
Minimum Web Browsing Requirements
‧Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD
‧256 MB RAM
‧AGP graphics card, Direct Draw, 32MB RAM
‧Windows 7, Vista & XP, DirectX 9.0 or later
‧Internet Explorer 7.x or later
