FEATURES
Easy network setup with your iPhone / iPad
POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce installation costs
ONVIF standard supported to simplify system integration
1.3 Megapixel SONY H.R. image sensor with HDTV 720p quality, allowing users to notice minor details more easily
External alarm I/O device connection
Microphone & speaker built-in for two-way audio transmission
Remote Surveillance
-- Fully compatibility
on iPhone & iPad, and Internet Explorer® on Windows® operating system
SPECIFICATIONS
▓
Network
Network Compression H.264 / MPEG4 / MJPEG
Multiple Video Streaming (Encode Modes, IPS, Resolution) 3 (H.264, MJPEG, MPEG4)
LAN Port YES LAN Speed 10/100 Based-T Ethernet
Supported Protocols DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP,
RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS
ONVIF Compatible YES
Frame Rate NTSC:30, PAL:25
Number of Online Users 10
Security
(1) Multiple user access levels with password
(2) IP address filtering
(3) Digest authentication
Remote Access (1) Internet Explorer on Windows operating system
(2) EagleEyes on iPhone, iPad & Android mobile devices
▓
Camera
Image Sensor 1/4" SONY H.R. image sensor
Video Resolution SXGA, 720P, VGA, QVGA
Min Illumination 0.1 Lux / F1.5, 0 Lux (LED ON)
Shutter Speed 1 / 2 to 1 / 10,000 sec.
S/N Ratio More than 48dB (AGC off)
Lens f3.8mm / F1.5
Viewing Angle 62.7°(Diagonal)
IR LED YES
IR Effective Range Up to 10 meters
IR Shifter YES
LED Indication YES
White Balance ATW
AGC Auto
IRIS Mode AES
POE YES (IEEE 802.3af)
External Alarm I/O YES
Microphone YES
Speaker YES
Power Source (±10%) 5V / 1A
Operating Temperature 0
℃~40℃
Dimensions (mm)** 126(L) x 87(W) x40 (H)
▓
Others
Mobile Surveillance iPad / iPhone / Android mobile device
RTC (real-time clock) YES
Motion Detection YES
Digital Pan / Tilt / Zoom YES
Event Notification FTP / Email
Minimum Web Browsing Requirements
‧Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD
‧256 MB RAM
‧AGP graphics card, Direct Draw, 32MB RAM
‧Windows 7, Vista & XP, DirectX 9.0 or later
‧Internet Explorer 7.x or later
