FEATURES
POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce
installation costs
ONVIF ( ) standard supported to simplify system integration
IR LED built-in for night surveillance up to 20 meters
IP66 weather-proof case for protection against dust and water, suitable for both indoor
& outdoor use
Remote Surveillance
Fully compatible with iOS and Android devices, and Internet Explorer on
Windows operating system
SPECIFICATION
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP,
RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS, SNMP
ONVIF Compatible YES (Profile S)
Number of Online Users 10
Security
(1) Multiple user access levels with password
(2) IP address filtering
(3) Digest authentication
Remote Access
(1) Internet Explorer on Windows operating system
(2) 16CH Video Viewer on Windows & MAC operating system
(3) EagleEyes on iPhone, iPad & Android mobile devices
Video
Network Compression H.264 / MPEG4 / MJPEG
Video Resolution 1280 x 1024 / 1280 x 720 / 640 x 480 / 320 x 240
Frame Rate 30fps
Multiple Video Streamaing 4 (H.264, MJPEG, MPEG4)
General
Image Sensor 1/ 3” SONY CMOS image sensor
Min Illumination 1 Lux / F1.5, 0 Lux (LED ON)
Shutter Speed 1/2 to 1/10,000 sec
S/N Ratio More than 48dB (AGC off)
Lens f3.8mm / F1.5
Viewing Angle 65.4° (Horizontal) / 49.9° (Vertical) / 80.4° (Diagonal)
IR LED 14 Units
IR Effective Distance Up to 20 meters
IR Shift YES
Smart Light Control YES
White Balance ATW
AGC Auto
IRIS Mode AES
POE YES (IEEE 802.3af)
IP Rating IP66
Operating Temperature -20℃ ~ 40℃
Power Source (±10%) 12V / 1A
Current consumption (±10%) 350mA
Power Consumption (±10%) 5.5W (PoE); 5.5W (PoN); 4.7W (DC Adapter)
Others
Mobile Surveillance iOS & Android mobile devices
Event Notification FTP / Email / SMS
Digital Pan / Tilt / Zoom YES
Motion Detection YES
RTC (real-time clock) YES
Minimum Web Browsing Requirements
‧Intel core i3 or higher, or equivalent AMD
‧2GB RAM
‧AGP graphics card, Direct Draw, 32MB RAM
‧Windows 8, 7, Vista & XP, DirectX 9.0 or later
‧Internet Explorer 7.x or later
*The specifications are subject to change without notice.
