Network
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols
DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP,
RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS, SNMP
Number of Online Users 10
Security
(1) Multiple user access levels with password
(2) IP address filtering
(3) Digest authentication
Remote Access
(1) Internet Explorer on Windows operating system
(2) 16CH Video Viewer on Windows & MAC operating system
(3) EagleEyes on iPhone, iPad & Android mobile devices
Video
Video Compression H.264 / MPEG4 / MJPEG
Resolution 1280 x 1024 / 1280 x 720 / 640 x 480 / 320 x 240
Frame Rate 30fps
Multiple Video Streaming 4 (H.264, MJPEG, MPEG4)
General
Image Sensor 1/4" SONY CMOS image sensor
Min Illumination 1 Lux / F1.4, 0 Lux (LED ON)
S/N Ratio More than 48dB (AGC off)
General
Electronic Shutter 1/2 to 1/10,000 sec
Lens f2.8 ~ 12mm / F1.4 ~ F2.8
Viewing Angle
Wide: 66° (Horizontal) / 52° (Vertical) / 90° (Diagonal)
Tele: 16° (Horizontal) / 10° (Vertical) / 22°(Diagonal)
IR LED 2 Units
IR Effective Range **
Default : up to 25 meters
IR Enhanced Mode : up to 35 meters
IR Shift YES
IRIS Mode AES
White Balance ATW
AGC Auto
MicroSD Card Slot YES (up to 64GB)
Heater YES
IP Rating IP66
Start-up Temperature -20℃ ~ 40℃
Operating Temperature -40℃ ~ 50℃
Power Source (±10%) 12V / 1.5A
Current Consumption (±10%) 1.32A
Power Consumption (±10%) 18.6W (PoE) ; 18.6W (PoN) ; 15.8W (DC Adapter)
Others
Mobile Surveillance iPad / iPhone / Android mobile device
ONVIF Compatible YES (Profile S)
POE (Power-over-Ethernet) YES (IEEE 802.3at)
Event Notification FTP / Email / SMS
Reset Default YES
External Alarm Device Connection YES
Digital Pan / Tilt / Zoom YES
Motion Detection YES
RTC (real-time clock) YES
Minimum Web Browsing Requirements
‧Intel core i3 or higher, or equivalent AMD
‧2GB RAM
‧AGP graphics card, Direct Draw, 32MB RAM
‧Windows 8, Windows 7, Windows Vista & Windows XP, DirectX 9.0 or later
‧Internet Explorer 7.x or later
