FEATURES
Zoom lens of f4.7 ~ 94mm with 20x optical zoom and auto focus, suitable for various monitoring environments.
PTZ control for seamless monitoring:
- Capable of 360° pan rotation continuously with the tilt movement of -6° ~ 90°, allowing quick and smooth action of the camera lens.
- Auto Tracking to follow moving objects.
- Hot Point support to quickly move the camera to the specified point remotely.
- Up to 256 preset points & four sequence group.
Programmable for multiple points monitoring, and auto pan.
External alarm I/O device connection
ONVIF standard supported to simplify system integration.
POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce installation costs.
MicroSD card support (up to 64GB) for video storage
Line in / out jacks available for audio transmission
DWDR to increase image recognizability in overexposure and dark areas
IR effective range up to 200 meters or more when the IR Turbo mode is on
IP66 for outdoor application
Remote Surveillance
-- Fully compatible with iOS and Android devices, and Internet Explorer on Windows operating system
-- Free PC program, CMS Lite, for 32CH devices monitoring on Windows operating system
-- Push Video available on your iOS and Android devices when used with Push Video NVR series.
SPECIFICATIONS
Network
LAN Port: YES
LAN Speed: 10/100 Based-T Ethernet
Supported Protocols: DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP,ICMP, SMTP, FTP, HTTP, RTP, RTSP, RTCP,IPv4, Bonjour,UPnP, DNS,UDP,IGMP, QoS, IEEE802.1X, SNMP
ONVIF Compatible: YES (Profile S)
Number of Online Users: 10
Security
(1) Multiple user access levels with password
(2) IP address filtering
(3) Digest authentication
Remote Access
(1) Internet Explorer on Windows operating system
(2) CMS Lite, 32CH CMS software for Windows operating system
(3) EagleEyes on iOS & Android mobile devices
Video
Network Compression: H.264 (Main Profile) / MJPEG
Video Resolution: 1920 x 1080 / 1280 x 720 / 720 x 480 / 352 x 240
Frame Rate: 30 fps
Multiple Video Streaming: 4 (H.264, MJPEG)
Bitrate Control: SVBR control (VBR + Max bitrate)
General
Image Sensor: 1/2.9" CMOS image sensor
Min Illumination: 0.1 Lux / F1.6 (Wide)~F3.5 (Tele), 0 Lux (IR LED ON)
Shutter Speed: 1 / 60 (1/50) to 1 / 100,000 sec.
S/N Ratio: More than 48dB (AGC off)
Lens: f4.7 ~ 94mm / F1.6 (Wide) ~ 3.5 (Tele), auto focus
Viewing Angle:
- 1X: 60.8° (Horizontal) / 35.3° (Vertical) / 68.3° (Diagonal)
- 20X: 3.4° (Horizontal) / 1.9° (Vertical) / 3.8° (Diagonal)
IR LED: 8 units
IR Effective Distance: Default: Up to 200 meters / IR Turbo mode: More than 200 meters
IR Shift: YES
White Balance: Auto / 2500K / 3200K / 4200K / 5800K / 9500K
AGC: YES
IRIS Mode: YES
Sharpness: YES
DWDR: YES
PoE*: YES
External Alarm I/O: YES (1 input / 1 output)
RAM: 20MB
MicroSD Card Slot: YES (up to 64GB)
RS-485: YES
IP Rating (weather-proof): IP66
Operating Temperature: -25°C ~ 50°C
Operating Humidity: 90% or less relative humidity
Power Source (±10%): AC 24V / DC19V
Current consumption (±10%): DC19V / 1.3A
Power Consumption (±10%): PoE / PoN: 25W; DC Adapter: 25W
Net Weight (kg): 6.9
* When PoE is used for power supply, the IR Turbo mode might not work properly.
Audio
Line in: YES
Line out: YES
PTZ Mechanism
Pan Range: 360° continuous rotation Max. Pan Speed 180º/s
Tilt Range: -6° ~ 90° Max. Tilt Speed 100º/s
Zoom Ratio: 20X Optical Zoom Max. Zoom Speed Approx. 3s (Tele ~ Wide)
Preset Points: Up to 256 preset points
Sequence Group:
1. Up to four groups can be set
2. One group can include up to 16 preset points
Auto Tracking: YES
Others
Mobile Surveillance: iOS & Android
Event Notification: FTP / Email / SMS
Digital Pan / Tilt / Zoom: YES
Reset Default: YES
Motion Detection: YES
RTC (real-time clock): YES
Minimum Web Browsing Requirements:
- Intel core i3 or higher, or equivalent AMD
- 2GB RAM
- AGP graphics card, Direct Draw, 32MB RAM
- Windows 10, Windows 8, Windows 7, Windows Vista & Windows XP, DirectX 9.0 or later
- Internet Explorer 7.x or later (Windows Edge not supported)
